NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant
  • NFC Apple Juice Production Line Pure Squeeze Processing Plant

NFC Apple Juice Production Line Pure Squeeze Processing Plant

Lugar de origem Xangai, China
Marca Gofun
Certificação CE, ISO
Número do modelo GFM-APL, GFM-PPL
Detalhes do produto
Garantia:
1 ano
Serviço pós-venda fornecido:
Engenheiros disponíveis para fazer manutenção em máquinas no exterior
Tensão:
220/380/440V, conforme clientes
Certificação:
CE/ISO9001
tipo:
Linha de processamento chave na mão
Material:
Padrão de alimentos Sus 304, 316, acumulando para o cliente
Capacidade:
20t/dia ~ 1500t/dia, de acordo com os clientes
Aplicativo:
Apple, Pear
Nome do produto:
Linha de processamento de suco de maçã/pêra
Produtos finais:
Suco NFC, suco nublado, suco transparente, suco de concentração, bebida
Processo especial:
HPP (processamento de alta pressão), UHP (processamento de pressão ultra-alta)
Termos de pagamento e envio
Quantidade de ordem mínima
1 conjunto
Preço
negotiable
Detalhes da embalagem
Pacote padrão internacional para envio
Tempo de entrega
45~90 dias
Termos de pagamento
T/T, União Ocidental, L/C
Habilidade da fonte
20 conjuntos por ano
Descrição do produto

High-Capacity Apple Juice and Puree Processing Plant – 24/7 Automated Operation

Designed for industrial-scale production, our complete apple juice making machinery handles capacities from 24 tons up to an impressive 480 tons of fresh fruit per day . The fully automated PLC control system governs the entire processing workflow—from the initial bubble washing and sorting to crushing, pressing, and enzymatic treatment. This high degree of automation dramatically reduces labor intensity and ensures consistent product quality across every batch .

Whether you are producing clear concentrated apple juice for export, NFC (Not From Concentrate) juice for premium retail, or apple paste for the baking industry, this versatile line delivers. The line incorporates a self-cleaning CIP (Clean-in-Place) system to maintain the highest sanitation standards with minimal downtime. Additionally, our efficient belt press extractor delivers an impressive juice yield of approximately 75% . We also provide customized voltage and power configurations to suit various global factory standards, ensuring seamless integration into your existing facility for immediate productivity gains.


Technical Specifications
Product NameOne-stop solution for apple processing line
Fresh Fruit Inlet Capacity500kg per hour ~ 25 tons per hour, customized
Raw MaterialFresh apple
End ProductsApple pulp, apple puree, apple juice, apple jam, dry apple and more
Final Product Brix10%~12%
Final PackagingAseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
Machine MaterialFood grade SUS304 or SUS316
Warranty12 months after commissioning
Operators RequiredAbout 10~12 persons
Voltage380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Key AdvantagesEnergy-saving, High efficiency, Water-saving, Stable performance
Production Process Overview
1Discharge Platform
Fresh apples are unloaded from trucks using a dedicated platform with water guns and transported to the production line via water flow. This area also serves as a pre-washing station before processing begins.
2Elevator
Transports fresh apples from external receiving areas into the processing facility.
3Washing
Fresh apples undergo thorough cleaning before skin and seed removal. Additional cleaning stages, including ultrasonic and ozone cleaning, can be integrated for enhanced sanitation.
Industrial apple washing machine with multiple cleaning stages
4Sorting
After washing, apples are visually inspected by operators to identify and remove any defective fruit, ensuring only quality produce proceeds to processing.
Quality control sorting station for apple inspection Close-up view of apple sorting conveyor system
5Crushing
GFM-FC series crushers utilize advanced technology for high-precision crushing of apples and other fruits. This fine grinding process enhances the efficiency of subsequent processing stages.
Industrial fruit crusher machine for apple processing
6Preheating
Crushed material is heated to temperatures between 45°C and 85°C. This step improves juice yield in subsequent extraction while preserving color and flavor characteristics.
Temperature-controlled preheating system for apple mash
7Belt Type Juice Extractor
Advanced belt press technology delivers high-efficiency juice extraction with over 70% yield. Features energy-saving design and automated control for optimal performance.
High-capacity belt press juice extractor for apples
8Sterilizing
Tube sterilizers process apple puree and applesauce at ultra-high temperatures (approximately 115°C for 30 seconds) followed by immediate cooling. This preserves taste and nutritional content while ensuring product safety.
Industrial tube sterilization system for apple products Control panel and monitoring system for sterilization process
9Aseptic Filling
Closed-loop aseptic filling systems work in conjunction with sterilizers. The filling chamber maintains vapor protection and sterile conditions, with mirror welding technology ensuring clean, smooth surfaces. Includes CIP and Auto SIP capabilities for various packaging formats.
Aseptic filling machine for sterile packaging of apple products Automated aseptic filling line operation
10Storage or Blending
Finished products can be stored directly or used as raw materials for further processing into apple sauce, ketchup, or other value-added products.
Storage tanks and blending systems for processed apple products
